Cement based hydraulic binder which is mixed with PLANOCOLOR GRANULATES MQ (quartz), PLANOCOLOR GRANULATES S (silica), PLANOCOLOR GRANULATES MR (marble), PLANOCOLOR GRANULATES LC (light & coated) and/or PLANOCOLOR GRANULATES RC GLASS recycled glass granulates in order to create highly resistant to wear micro-pebble coverings on horizontal or vertical surfaces. It can also be mixed with pigments such as NOVACOLOR OXIDE, NOVACOLOR CARBON or NOVACOLOR UNIVERSAL. These coverings depending on the type of granulates used in the mix can be applied as final covering also inside swimming pools. They are applied in a thickness of 6mm (walls) and 10 – 20 mm (floors) depending on the grain size of the used granulates. The granulates used inside the mix reveal after 12 – 48 hours by means of an appropriate “washing” process with water, ACID CLEAN TURBO and/or antique brushes. The PLANOCOLOR CRT 052 surface retardant can be used during this process in order to facilitate the whole operation. Mixing ratio: 20 – 35% by weight of the dry mix.
• NOVACEM CREATIVE cement-based hydraulic binder can be used:
o in applications such as:
o textured, non slip surfaces with natural optic
o furniture, tables, offices, benches
o for horizontal and vertical applications:
o exterior areas, landscape design, swimming pools, etc.
o interior areas, bath rooms and wet areas
o under floor heating floors
o in areas with heavy traffic, showrooms, commercial centers, public buildings, or offices
o furniture, tables, offices, benches
o for placement on various substrates such as:
o concrete or screeds
o existing coatings such as tiles, natural stones
o mortars and masonry mortars
o cement boards and gypsum boards (with a suitable primer)
Remark: Due to printing and application procedure, the colors and their final appearance presented here and in every catalogue or brochure, should be considered as indicative.
• Form: Powder
• Chemical substance: Portland cement, special additives
• Density of the mix: 2,1 ± 0,1 kg/L
• Dry density of the mix: 2,0 ± 0,1 kg/L
• Workability: ≈ 60 min / 20°C
• Walkability: 2 – 3 hours
• Application temperature: from +5°C up to +35°C
Substrate preparation:
Concrete and cement mortars must be dry, sufficiently mature, and free from the risk of cracking. Furthermore, the surface must be free of dust, dirt, oils, grease, rust, and other elements that will interfere with adhesion. Remove all loose and friable sections of concrete or cement mortar until the substrate is compact and firm with a tensile strength of at least 1.5 N/mm². Existing cracks should be repaired with two-component injectable epoxy adhesive EPO FLUID. Substrates with low mechanical strength must be reinforced with NOVAPRIMER or WATER PRIMER EPX, as needed.
If the application takes place in a swimming pool, outside, or wet areas, waterproofing with SC ELASTIC, SC 200 PENETRATE, or SC ELASTIC EASY is recommended. Use EPO FLUID or an adhesive primer consisting of 1-part SBR 50, 1 part water, and 3 parts NOVACEM CREATIVE for monolithic bonding to the substrate and apply the mortar fresh on fresh to the adhesive layer.
If the surface has been properly cleaned, it is recommended to pre-coat with PLANO CONTACT FAST on surfaces with low absorbency, such as old mosaics, well-fixed ceramic tiles, or marbles. Please refer to the Product Data Sheets for more information.
Preparation of the mix:
Fill a suitable concrete or pan mixer with the required amount of water. Add NOVACEM CREATIVE to the water slowly while stirring, followed by the aggregates. Mix for at least 3 minutes, or until the mixture is completely homogenized and free of lumps. The mixture is now ready to be used.
Application:
Using a flat spatula or trowel, apply the mixture. Final smoothing can be accomplished with finishing tools such as a flat metal trowel. The application thickness is determined by the maximum grain size of the aggregates used, with the minimum thickness being 2-3 times the aggregates' maximum grain size. When applying thicker coats, apply a second coat if the first does not stick to the hand.
Under normal conditions, the mortar should be applied within 60 minutes of mixing. After this time, do not attempt to mix it with water again. Low temperatures prolong the life of the mortar, whereas high temperatures significantly reduce workability.
Spray the surface retarder PLANOCOLOR CRT 052 within 30 minutes of applying the mortar. To bring out the decorative aggregates, rinse the surface with high-pressure water (100 to 180 bar) 12 to 24 hours after application, but no later than 3 days. If it rains during the waiting period, it is best to remove it right away. Mechanical cleaning agents such as antique marble brushes can be used to highlight the decorative aggregates. The type of antique brush used depends on the application and ranges from No. 60 to 180.
Use a Scotch-Brite type sponge for small vertical surfaces. The waiting time is determined by the environmental conditions.
Note: If the aggregates are dormant during the removal of the material from the surface, reduce the water pressure or wait a longer time.
It is recommended to use the mineral hardener/concrete densifier PLANOFINISH CH PLUS 24 - 48 hours after the completion of the cleaning and depending on the type of application in applications under difficult weather conditions. Floor applications should be protected with PROTECT 200, PROTECT 300 S and/or WET PLUS S depending on the application requirements. When using NOVACEM CREATIVE inside swimming pools, it is not recommended to use a varnish or surface protection.
Expansion joints:
The location of each expansion joint is determined by the surface's use and the geometry of the space. The general rules for mortar manufacturing, as well as the guidelines of the BS 8204-3 standard, must be followed. An expansion joint is recommended in swimming pools at wall-to-floor and wall-to-wall joints, as well as every 40 - 45m². Specific joints must be properly sealed, for example, with NOVAMIX PU 500 or NOVACOLOR HNR.
Recommendations:
• Apply in structurally stable and well-prepared surface
• Avoid application with direct exposure to sunlight and/or strong wind as well as rain
• Once the mixture begins to set, do not add any more water or additives
• Do not apply to existing substrate expansion or movement joints
• Do not mix NOVACEM CREATIVE with gypsum, cement, resins, latex, or other binders
• Do not use on non-absorbent substrates such as metal, glass, old ceramic tiles, and mosaics without first applying an appropriate primer
• After 7-10 days, complete immersion in water
• Do not apply when temperature of the substrate and environment is lower than +5°C and higher than +35°C
• Do not apply directly to anhydride substrates, metal, flexible or high vibration surfaces
• It is not recommended to use different batches on uniform surfaces. Where a specific shade is required, mixing with NOVACOLOR OXIDE or NOVACOLOR UNIVERSAL in an appropriate proportion is recommended
• Use NOVACEM TERRAZZO to make polished mosaics
• Application must be done by professional applicators
Cleaning:
Tools used during the preparation and application can be cleaned with water while NOVACEM CREATIVE is still fresh. If hardening occurs, cleaning can be done only by mechanical means.
Legal Notice:
The technical data and recommendations included or listed are the outcome of laboratory measurements combined with our current knowledge and expertise. All information and specifications should in any case be considered as indicative. The Company makes every effort to ensure the accuracy of the information provided herein. Product specifications are subject to change without notice and may differ from product images. Due to printing and application procedures, the colors displayed here should be considered as indicative. In particular, variations in materials, substrates and on-site application conditions are such that no warranty can be given or implied reference to the suitability of the materials for trading or use for a particular purpose and conditions of any given project. Anyone interested in using the product must ensure beforehand that the product is suitable for the intended use and in any case, the user is solely responsible for any outcomes associated with the use of product. Among other things, the Company is not responsible for any normal wear or tear from environmental or any other unsuitable conditions. We reserve the right to revise or change the data herein without prior notice. Restrictions and disclaimers apply to the extent permitted by applicable law. The Company has a Technical Support Department, which has exclusive responsibility for providing technical advice and solutions, addressing relevant issues. Requests to the Technical Support Department are addressed and answered, only in writing. For the latest and valid version of the Technical Data Sheet, the user of the material must refer to our website www.novamix.gr.
